G4-23 Pump Head Testing Transfer Box Fixture for Kubota CAT Bomag

G4-23 Series Pump Head Testing Transfer Box

The G4-23 series transfer box is a specialized fixture designed for diesel fuel injection pump test benches. It allows for the precise testing of pump heads for various engine brands including Kubota, Caterpillar (CAT), Bomag, and Perkins.

How to Choose the Correct Model

• Step 1: Determine the number of cylinders in your pump.
• Step 2: Measure the pump flange dimensions (A * B). The tolerance is ±1mm.

Model Specifications

Model	Pump Head Size (mm)	Application / Compatibility
DT-4	155 * 80	Bomag Rollers
XT-6	185 * 80	Kubota 6-Cylinder
XT-4	128 * 80	Kubota
TB-4	105 * 65	Kubota
TB-6	195 * 85	Kubota 6-Cylinder
TB-3	88 * 78	Perkins
DT-3	102 * 78	Kubota, Carter (CAT)
XT-5	Multi-function	Kubota 5-Cylinder
XT-3	84 * 65	Kubota, Carter (CAT)
FT-3	93 * 91	Kubota, Carter (CAT)
XT-2	65*64 / 65*72	Kubota 2-Cylinder

Note: The pump head couplings shown in images are for demonstration purposes only. Multi-function models may vary in price.
